Random Noise, Sample Acquisition Mode
Performance checks Vertical sensitivity = 100 mV/div
1 MΩ 50 Ω
Bandwidth Test result (mV) High limit (mV) Test result (mV) High limit (mV)
Channel 4 Full 4.5 4.5
250 MHz limit 3.7 3.8
20 MHz limit 3.0 4.0
MSO5034B, DPO5034B, MSO5054B, DPO5054B
Channel 1 Full 5.0
250 MHz limit 4.75
20 MHz limit 4.00
Channel 2 Full 5.00
250 MHz limit 4.75
20 MHz limit 4.00
Channel 3 Full 5.00
250 MHz limit 4.75
20 MHz limit 4.00
Channel 4 Full 5.00
250 MHz limit 4.75
20 MHz limit 4.00
Sample Rate and Delay Time Accuracy
Performance checks Low limit Test result High limit
-0.8 divisions +0.8 divisions
Delta Time Measurement Accuracy
Performance checks
MSO/DPO5204/B Channel 1
Sample rate = 10 GS/s, 4 ns/Div, Source freq = 240 MHz
MSO/DPO V/Div Source V
pp
Test result High limit
1 mV 8 mV NA
5 mV 40 mV 65 ps
100 mV 800 mV 61 ps
500 mV 4 V 61 ps
1 V 4 V 70 ps
Sample rate = 5 GS/s, 40 ns/Div, Source freq = 24 MHz
Performance verification (MSO/DPO5000/B series)
302 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
