Test at 62.5 mVFS, 50 mVFS, 100 mVFS.
MSO/DPO73304DX at
100 GS/s, BWE on
6.25 mV/div, <10 ns measurement interval, 19.49 GHz, amplitude = 80% FS, 0.803 ps rms,
8.03 ps
pk-pk
50 mV/div, <10 ns measurement interval, 19.49 GHz, amplitude = 80% FS, 0.564 ps rms,
5.64 ps
pk-pk
100 mV/div, <10 ns measurement interval, 19.49 GHz, amplitude = 80% FS, 0.555 ps rms,
5.55 ps
pk-pk
MSO/DPO72504DX at
100 GS/s, BWE on
6.25 mV/div, <10 ns measurement interval, 15.53 GHz, amplitude = 80% FS, 0.881 ps rms,
8.81 ps
pk-pk
50 mV/div, <10 ns measurement interval, 15.53 GHz, amplitude = 80% FS, 0.639 ps rms,
6.39 ps
pk-pk
100 mV/div, <10 ns measurement interval, 15.53 GHz, amplitude = 80% FS, 0.639 ps rms,
6.39 ps
pk-pk
MSO/DPO72304DX at
100 GS/s, BWE on
6.25 mV/div, <10 ns measurement interval, 14.28 GHz, amplitude = 80% FS, 0.889 ps rms,
8.89 ps
pk-pk
50 mV/div, <10 ns measurement interval, 14.28 GHz, amplitude = 80% FS, 0.666 ps rms,
6.66 ps
pk-pk
100 mV/div, <10 ns measurement interval, 14.28 GHz, amplitude = 80% FS, 0.677 ps rms,
6.77 ps
pk-pk
MSO/DPO73304DX at
100 GS/s, BWE off, typical
6.25 mV/div, <10 ns measurement interval, 19.49 GHz, amplitude = 80% FS, 0.888 ps rms,
8.88 ps
pk-pk
50 mV/div, <10 ns measurement interval, 19.49 GHz, amplitude = 80% FS, 0.577 ps rms,
5.77 ps
pk-pk
100 mV/div, <10 ns measurement interval, 19.49 GHz, amplitude = 80% FS, 0.577 ps rms,
5.77 ps
pk-pk
MSO/DPO72504DX at
100 GS/s, BWE off, typical
6.25 mV/div, <10 ns measurement interval, 15.53 GHz, amplitude = 80% FS, 0.108 ps rms,
1.08 ps
pk-pk
50 mV/div, <10 ns measurement interval, 15.53 GHz, amplitude = 80% FS, 0.673 ps rms,
6.73 ps
pk-pk
100 mV/div, <10 ns measurement interval, 15.53 GHz, amplitude = 80% FS, 0.673 ps rms,
6.73 ps
pk-pk
MSO/DPO72304DX at
100 GS/s, BWE off, typical
6.25 mV/div, <10 ns measurement interval, 14.28 GHz, amplitude = 80% FS, 0.109 ps rms,
1.09 ps
pk-pk
50 mV/div, <10 ns measurement interval, 14.28 GHz, amplitude = 80% FS, 0.701 ps rms,
7.01 ps
pk-pk
100 mV/div, <10 ns measurement interval, 14.28 GHz, amplitude = 80% FS, 0.713 ps rms,
7.13 ps
pk-pk
Delta time measurement
accuracy ≥4 GHz, ≤20 GHz models
The formula to calculate the maximum delta-time measurement accuracy (DTAmax) for a given
instrument setting and input signal is given below (assumes insignificant signal content above
Nyquist and insignificant error due to aliasing, overdrive recovery and overdrive interpolation):
SR1 = slew rate around 1st point in measurement (1st edge)
SR2 = slew rate around 2nd point in measurement (2nd edge)
FN = 1.3 for instrument bandwidth ≤9 GHz; 1.5 for instrument bandwidth ≥10 GHz
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Horizontal and acquisition system
(cont.)
54 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
