Tektronix DPO5000 Series Technical Reference

Ntyp = typical input-referred noise spec (volts rms)
TBA = timebase accuracy (1.5 ppm)
treading = delta-time measurement (seconds)
Peak-peak based on statistical accumulation of 1000 waveforms.
DTA
MAX
pk-pk
= 10 × (N
typ
× F
N
)
2
(
1
SR
1
)
2
+
(
1
SR
2
)
2
+ 1ps
2
+ (2 × 10
-9
× t
reading
)
2
+
TBA × t
reading
seconds
pk-pk
RMS is guaranteed regardless of data-gathering duration.
DTA
MAX
RMS
= (N
typ
× F
N
)
2
(
1
SR
1
)
2
+
(
1
SR
2
)
2
+ 1ps
2
+ (2 × 10
-9
× t
reading
)
2
+
TBA × t
reading
seconds
RMS
The term under the square-root sign is the stability and is due to time interval error (TIE). The
errors due to this term occur throughout a single-shot measurement. The second term is due to
both the absolute center-frequency accuracy and the center-frequency stability of the timebase and
varies between multiple single-shot measurements over the observation interval (the amount of
time from the first single-shot measurement to the final single-shot measurement). The observation
interval may not exceed 1 year.
Test at maximum bandwidth. Test at 10 mV, 50 mV, 100 mV.
MSO/DPO72004C at 500 GS/s
(IT mode), BWE off
10 mV/div, <10 ns measurement interval, 9.94 GHz, amplitude = 80% FS, 1.280 ps rms,
12.80 ps
pk-pk
50 mV/div, <10 ns measurement interval, 9.94 GHz, amplitude = 80% FS, 1.172 ps rms,
11.72 ps
pk-pk
100 mV/div, <10 ns measurement interval, 9.94 GHz, amplitude = 80% FS, 1.186 ps rms,
11.86 ps
pk-pk
MSO/DPO71604C at 500 GS/s
(IT mode), BWE off
10 mV/div, <10 ns measurement interval, 9.94 GHz, amplitude = 80% FS, 1.280 ps rms,
12.80 ps
pk-pk
50 mV/div, <10 ns measurement interval, 9.94 GHz, amplitude = 80% FS, 1.172 ps rms,
11.72 ps
pk-pk
100 mV/div, <10 ns measurement interval, 9.94 GHz, amplitude = 80% FS, 1.186 ps rms,
11.86 ps
pk-pk
MSO/DPO71254C at 500 GS/s
(IT mode), BWE off
10 mV/div, <10 ns measurement interval, 7.76 GHz, amplitude = 80% FS, 1.304 ps rms,
13.04 ps
pk-pk
50 mV/div, <10 ns measurement interval, 7.76 GHz, amplitude = 80% FS, 1.201 ps rms,
12.01 ps
pk-pk
100 mV/div, <10 ns measurement interval, 7.76 GHz, amplitude = 80% FS, 1.205 ps rms,
12.05 ps
pk-pk
MSO/DPO70804C at 500 GS/s
(IT mode), BWE off
10 mV/div, <10 ns measurement interval, 4.97 GHz, amplitude = 80% FS, 1.462 ps rms,
14.62 ps
pk-pk
50 mV/div, <10 ns measurement interval, 4.97 GHz, amplitude = 80% FS, 1.295 ps rms,
12.95 ps
pk-pk
100 mV/div, <10 ns measurement interval, 4.97 GHz, amplitude = 80% FS, 1.336 ps rms,
13.36 ps
pk-pk
Horizontal and acquisition system (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 55
