Tektronix DPO5000 Series Service Manual

Replaceable Parts (DPO7000 Series)
Table 5-4: Repl
aceable parts – μATX Motherboard (DPO7000 Series)
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & descript
ion
5-4 and 5-5
MOTHERBOARD
050-3723-00 1
PARTS REPLACEMENT KIT; AIMB562VG-00A1E, BIOS 562X12AN.BIN,
ALC888 AUDIO
CODEC, 039018601 WITH 063425400 AIMB-562 AUDIO
DRIVER, ADVANTECH VERSION 5.10.0.5324
-1
167-0657-00 1
PROCESSOR;
PENTIUM 4, 3.4 GHZ INTERNAL CLOCK, 400MHZ BUS,
SOCKET 478 COMPATIBLE, W/O FAN HEATSINK, JM80547PG0961M
-2 119-7333-00 1
FAN AND HEAT
SINK WITH BRACKET
-3 1
BRACKET FOR FAN AND HEATSINK
(PARTOFIT
EM 2 IN THIS LIST)
167-0428-00 B010100 B010856 4
IC, MEMORY; 64M X 64, 512 MB DDR2, 1.8V, 3-3-3;
MT16HTF64
64AY-40E, DIMM240, DS1
-4
167-1048-00 B010857 2
IC, MEMORY; 128M X 64, 1 GB DDR2, 1.8V, 3-3-3;
MT16HTF1
2864AY-40E, DIMM240, DS1
-5
174-5271-00 1
IDE CABLE W ITH STRAIN RELIEF & PULL-TAB
-6 211-105
0-00
5
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
-7
174-4797-00 1
CA ASSY;
20 PIN ATX POWER, SAFETY CONTROLLED
-8 174-4865-00 1
CA ASSY; 4 PIN P4 POWER, 9.5 L, MOTHER BOARD TO INTERFACE
BOARD,
SAFETY CONTROLLED
441-2466-01 1
CHASSIS; REAR PROCESSOR, 039-0173-xx
-9
441-25
51-00
1
ATX CHASSIS; MOTHERBOARD ADVANTECH AIMB-562, 039-0185-xx
065-0826-00 B110100 1
DISK D
RIVE ASSY;SERVICE REPLACEMENT, UNPROGRAMMED
HARD DRIVE 1197524XX W/ PACKAGING; DPO/DSA70000B
MSO70000/C, DSA70000B/C, DPO70000B/C, D PO7000, MSO5000, DPO5000 Series 5–9
