Replaceable Parts (MSO/DPO5000 Series)
Replaceable P
arts (MSO/DPO5000 Series)
The followin
g tables and illustrations show the replaceable parts for the MSO5000
Series and DPO5000 Series products.
Two tables p
rovide the replaceable cable part numbers:
(See Table 5-30 on page 5-62.)
(See Table 5-31 on page 5-63.)
Two figures show how to attach the connectors in the instrument:
(See Figure 5-32 on page 5-62.)
(See Figure 5-33 on page 5-63.)
Table 5-26: Replaceable parts – Front panel assembly (MSO/DPO5000 Series)
Figure
and
index
no.
Tektronix
part no.
Serial
no.
effective
Serial
no.
discont’d Qty. Name and description
5-28-
FRONT PANEL ASSEMBLY
-1 065-0853-00 1
FRONT CASE ASSEMBLY
-2 366-0861-01 2
ASSEMBLY, KNOB: .925 DIAMETER, SOFT TOUCH
-3 366-0865-00 1
KNOB ASSEMBLY, SHUTTLE AND BUSHING
-4 366-0867-01 1
KNOB ASSEMBLY, JOG
-5
366-0859-01 6
ASSEMBLY, KNOB: .470 DIAMETER, SOFT TOUCH
-6 366-0860-01 6
ASSEMBLY, KNOB: .685 DIAMETER, SOFT TOUCH
-7
260-2898-00 1
SWITCH, KEYPAD, ELASTOMERIC, POWER
-8 407-5259-00 1
BRACKET, SUPPORT: POWER SW ITCH
SCREW, MACHINE: 6–32 x 0.250, PNH, STL, ZNPL, T-15 TORX DRIVE
--------DISTRIBUTIONOFTHE211-1273-00SCREWS---------
2 screws attach the Power switch and bracket to the front case assembly.
2 screws attach the Utility switch and bracket to the front case assembly.
10 screws attach the Front panel assembly to the front case assembly
– with contact springs (#14).
-9 211-1273-00 19
5 screws across the bottom of the Front panel assembly attach it to the front case assembly
– without contact springs.
-10 260-2899-00 1
SWITCH, KEYPAD, ELASTOMERIC, UTILITY
-11 407-2567-00 1
BRACKET, SUPPORT, UTILITY SWITCH
-12 260-2901-00 1
SWITCH, KEYPAD, ELASTOMERIC, FRONT PANEL
-13 877-0277-01 1
CIRCUIT BOARD ASSEMBLY, FRONT PANEL
-14 131-8139–00 10
CONTACT, SPRING: FRONT PANEL ELEC
5–54 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
