Replaceable Parts (DSA/DPO70000B Series)
Table 5-14: Rep
laceable parts – Drives (DSA/DPO70000B Series)
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial
no.
discont’d Qty Nam e & description
5-16
DRIVES
-1 065-0851-00 1
DISK DRIVE ASSY;SERVICE REPLACEMENT, PROGRAMMED
HARD DRIVE
-2 211-1050-00 8
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
-3 407-5069-00 1
BRACKET, RHDD; SATA COMBO CABLE, 3.5 INCH REMOVABLE
HARD DISK DRIVE RECEPTACLE
-4 174-5169-00 1
CABLE ASSY; SATA COMBO, HARD DRIVE CABLE
-5
174-5017-00 1
CABLE ASSEMBLY; DVD POWER
-6 679-5915-00 1
CKT BD SUBASSY; DVD-CD/RW ADAPTER, UNTESTED,
389-3689-00 WIRED
-7
129-1618-00 1
SPACER; DVD-CD/RW SLIMLINE DRIVE ADAPTER, PLASTIC
-8 211-0950-00 4
SCREW, MACHINE; M2X.4X3L, PHL, PNH, STL NI PL
-9 407-5156-00 1
BRACKET, DVD-CD/RW; ADAPTER FOR DVD-CD/RW SLIMLINE
-10 119-7196-00 1
DISK DRIVE; OPTICAL, 644MB, CD-RW/DVD ROM, COMBO,
16.7 MB/SEC, IDE/ATAPI; DW-224E-C93
-11 441-2496-01 1
CHASSIS; DRIVE BAY; METAL
5–30 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
