Tektronix DPO5000 Series Service Manual

Replaceable Parts (DSA/DPO70000B Series)
Table 5-11: Rep
laceable parts – μATX assembly (DSA/DPO70000B Series)
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial
no.
discont’d Qty Name & description
5-12 and 5-13
MOTHERBOARD
-1 174-4797-00 1
CA ASSY; 20 PIN ATX POWER, SAFETY CONTROLLED
065-0745-02 1
SERVICE KIT FOR CPU BRD, CPU, FAN AND HEAT SINK
ASSEMBLY
167-0657-00 1
PROCESSOR; PENTIUM 4, 3.4 GHZ INTERNAL CLOCK, 400MHZ
BUS, W/O FAN HEATSINK, HH80552PG0962M
-2
119-7333-00 1
FAN, HEATSINK AND BRACKET
-3 211-0935-00 8
SCREW, MACHINE; 6-32 X 0.50, PNH, T-15, SST, PASSIVATED
-4 174-4798-00 1
CA ASSY; 4 PIN P4 POWER
-5
050-3723-00 1
PARTS REPLACEMENT KIT; AIMB562VG-00A1E, BIOS
562X12AN.BIN, ALC888 AUDIO CODEC, 039018601 WITH
063425400 AIMB-562 AUDIO DRIVER, ADVANTECH VERSION
5.10.0.5324; DPO7000, DPO/DSA70000, DPO/DSA7000B, VM6000,
DSA8200, TLA5000B SERIES
-6 167-1048-00 2
IC, MEMORY; 128M X 64, 1GB DDR2 1.8V, 3-3-3;
MT16HTF12864AY-40E, DIMM240,DS1
-7
119-7333-00 1
HEATSINK AND BRACKET
-8 342-1198-00 1
DAMPENER, PORON FOAM FOR P4 HEATSINK
-9 174-5271-00 1
IDE CABLE WITH STRAIN RELIEF & PULL-TAB
5–24 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
