Name: Tektronix DPO70000SX Series
Brand: Tektronix
Rating: 4 (1 reviews)

To Next Page

To Previous Page

Graphic indicator

Increment/Decrement buttons

Pop-up keypad

1. Double click in a data entry box, or:

■

Click in a data entry box.

■

Click on the keypad icon.

2. Use the pop-up keypad to enter data.
