Appendix
Performance Graphs
Refer to the reference lead derating curve above when making floating measurements.
Table 2: Environmental specifications
Characteristics Description
Temperature
Operating
Nonoperating
–15°Cto+65°C(+5°Fto+149°F)
–62 °C to +85 °C (–80 °F to +185 °F)
Humidity
Operating
Nonoperating
5% to 95% relative humidity @ up to 30 °C
5% to 45% relative humidity @30 °C up to 50 °C
Altitude
Operating
Nonoperating
4.6 km (15,000 ft) maximum
12.2 km (40,000 ft) maximum
Table 3: Certifications and compliances
Characteristics Description
EC Declaration of
Conformity
Compliance was demonstrated to the following specification as listed i n the Official Journal
of the European Communities:
Low Voltage Directive 2006/95/EC:
EN61010-031: 2002
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DP O5000 Series U ser M anual 175
