12. Turn channel displays on and off.
Vertically scale o r position the waveform.
On MSO5000B Se
ries instruments,
turn on digital channels by pushing
the D15–D0 button or using the Digital
> Digital Set
up menu. (See page 51,
Setting up digital signal input.)
13. Push to turn the touch screen on and off.
14. Push to display the math, reference, bus,
or vertical setup menus.
15. Push to turn off a displayed menu.
16. Push to a ccess the digital setup menu
(MSO5000B
Series only).
17. Push to cl
ear data.
18. Pushtore
turn settings to default values.
19. Pushtosa
ve and recall setups,
waveforms, and screen images.
20. Push to make a hard copy or save a
screen capture.
MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series User Manual 27
