DC voltage measurement accuracy (averaged), >20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch4 200 mV Vert scale setting, 0 Div position setting
0 V termination
–1 V offset
0 V offset
+1 V offset
-456.5 mV
547.5 mV
1.5435 V
__________
__________
__________
__________
__________
__________
-343.5 mV
652.5 mV
1.6565 V
Ch4 400 mV Vert scale setting, 0 Div position setting
0 V termination
–1 V offset
0 V offset
+1 V offset
103.5 mV
1.1075 V
2.1035 V
__________
__________
__________
__________
__________
__________
296.5 mV
1.2925 V
2.2965 V
DC voltage measurement accuracy (averaged), ≥4 GHz, ≤20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch1 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
+ 524.75 mV __________ __________ + 535.25 mV
Ch1 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
- 535.25 mV __________ __________ - 524.75 mV
Ch1 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
+ 552.75 mV __________ __________ + 567.25 mV
Ch1 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
- 567.25 mV __________ __________ - 552.75 mV
Ch1 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
+ 636.75 mV __________ __________ + 663.25 mV
Ch1 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
- 663.25 mV __________ __________ - 636.75 mV
Ch1 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
+ 2.764 V __________ __________ + 2.836 V
Ch1 100 mV Vert scale setting,
+5 Div position setting, -2.0 V offset
- 2.836 V __________ __________ - 2.764 V
Ch1 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
+ 2.697 V __________ __________ + 2.803 V
Ch1 200 mV Vert scale setting,
+5 Div position setting, -1.25 V offset
- 2.803 V __________ __________ - 2.697 V
Ch1 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
+ 3.394 V __________ __________ + 3.606 V
Ch1 500 mV Vert scale setting,
+5 Div position setting, 0 V offset
- 3.606 V __________ __________ - 3.394 V
Ch2 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
+ 524.75 mV __________ __________ + 535.25 mV
Ch2 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
- 535.25 mV __________ __________ - 524.75 mV
Ch2 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
+ 552.75 mV __________ __________ + 567.25 mV
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
134 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
