Horizontal and acquisition system
Real-time sample rate range
Number of channels
acquired
Sample rate, maximum
(Standard) (Option 2SR)
MSO/DPO70804C
MSO/DPO70604C
MSO/DPO70404C
All channels Up to 25 GS/s
MSO/DPO73304DX
MSO/DPO72504DX
MSO/DPO72304DX
MSO/DPO72004C
MSO/DPO71604C
MSO/DPO71254C
All channels Up to 50 GS/s
Two channels Up to 100 GS
DPO7354C and
DPO7254C
1 40 GS/s
2 20 GS/s
3 or 4 10 GS/s
DPO7104C 1 20 GS/s 40 GS/s
2 10 GS/s 20 GS/s
3 or 4 5 GS/s 10 GS/s
DPO7054C 1 20 GS/s
2 10 GS/s
3 or 4 5 GS/s
Equivalent-time sample rate or
interpolated waveform rate range
Equivalent-time acquisition can be enabled or disabled. When disabled, waveforms are interpolated
at the fastest time base settings.
≥4 GHz models Up to 5 TS/s and 0.2 ps trigger placement resolution
<4 GHz models Up to 4 TS/s
Maximum record length, sample
mode, ≥4 GHz models
The maximum record length depends on the installed record length options. Maximum record
length is less in serial trigger mode, hi-res mode, or when using the FIR filter.
Option 2XL installed
(standard on DPO70000C/DX Series)
31,250,000 points
Option 5XL installed
(standard on MSO70000C/DX Series)
62,500,000 points (all channels)
Option 10XL installed 125,000,000 points (all channels)
Option 20XL installed 250,000,000 points (all channels)
Option 50XL installed (DX models only) 500,000,000 points (all channels), 1 G on 1–
2 channels at 50 GS/s and 100 GS/s sample
rates or greater (interpolated or equivalent time)
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
48 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
