Performance verification (MSO/DPO5000/B series)
Performance verification (MSO/DPO5000/B series)
This chapter contains performance verification procedures for the specifications
marked with the symbol. The following equipment, or a suitable equivalent, is
required to complete these procedures.
Required equipment
1. DC voltage source
Minimum requirements Examples
3 mV to 4 V, ±0.1% accuracy Fluke 9500B Oscilloscope Calibrator with a
9530 Output Module
2. Leveled sine wave generator
50 kHz to 2 GHz, ±4% amplitude accuracy
3. Time mark generator
80 ms period, ±1 ppm accuracy, rise time
<50 ns
4. Logic Probe(MSO5000/B Series only)
Low capacitance digital probe, 16 channels. P6616 probe; standard accessory for
MSO5000/B Series oscilloscopes.
5. BNC-to-0.1 inch pin adapter to connect the logic probe to the signal source.
(MSO5000/B Series only)
BNC-to-0.1 inch pin adapter; female BNC to
2x16 .01 inch pin headers.
Tektronix adapter part number 679-6240-00;
to connect the Fluke 9500 to the P6616
probe.
6. Digital Multimeter (DMM)
0.1% accuracy or better
7. One 50 Ω terminator
Impedance 50 Ω; connectors: female BNC
input, male BNC output
Tektronix part number 011-0049-02
8. One 50 Ω BNC cable
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 285
