Tektronix DSA70000D Series Technical Reference

Channel-to-channel crosstalk
(channel isolation)
>20 GHz models, typical Input frequency range (up to the rated bandwidth). Assumes two channels with the same scale and
bandwidth settings.
0 to 9 GHz ≥ 120:1 isolation
>9 to 12 GHz ≥ 80:1 isolation
>12 to 15 GHz ≥ 50:1 isolation
>15 to 20 GHz ≥ 25:1 isolation
>20 to 33 GHz ≥ 20:1 isolation
≥ 4 GHz, ≤20 GHz models,
typical
Input frequency range (up to the rated bandwidth). Assumes two channels with the same scale and
bandwidth settings.
0 to 10 GHz ≥ 120:1 isolation
>10 GHz to 12 GHz ≥ 80:1 isolation
>12 GHz to 15 GHz ≥ 50:1 isolation
>15 GHz to 20 GHz ≥ 25:1 isolation
<4 GHz models, typical RMS voltage ratio of ≥ 100:1 at ≤ 100 MHz and ≥ 30:1 at > 100 MHz up to 2.5 GHz, and
≥20:1 above 2.5 GHz
Delay between channels, BWE,
typical
>20 GHz models ≤ 1 ps between any two channels at any gain setting at 25 °C ±5 °C. Derate linearly to ≤ 3 ps at
5 °C and 45 °C.
Delay between channels, full
bandwidth, equivalent time, typical
>20 GHz models ≤ 3 ps between any two channels at any gain setting at 25 °C.
≤ 10 ps for any two channels at any gain setting over temperature.
≥ 4 GHz, ≤20 GHz models ≤ 10 ps between any two channels with equal volts/div and coupling settings.
≤ 10 ps delay change when enabling and disabling Channel Equalization (DSP matching).
Delay between channels, typical
<4 GHz models
≤ 100 ps between any two channels with the same scale and coupling settings with input
impedance set to 50 Ω, DC coupling and scale set at or above 10 mV/div.
Internal probe power <4 GHz
models
50 W maximum
Probe power per probe, <4 GHz
models
Voltage Maximum Amperage Voltage Tolerance
5 V 50 mA ± 5%
12 V 1 A ±10%
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 47
