Tektronix DSA70000D Series Technical Reference

Ch Scale
setting
Termination
setting
Position
setting
(Divs)
Offset
setting
Generat
or
setting
Measurement
mean
Difference of
measurement
means
Accuracy limits
Ch1 20 mV 0 V 0 0 V 60 mV +117.6 mV to
+122.4 mV
-60 mV
0 +1 V 1.06 V +117.6 mV to
+122.4 mV
940 mV
0 -1 V -940 mV +117.6 mV to
+122.4 mV
-1.06 V
1.5 V 0 2.5 V 2.56 V +117.6 mV to
+122.4 mV
2.44 V
0 1.5 V 1.56 V +117.6 mV to
+122.4 mV
1.44 V
0 0.5 V 560 mV +117.6 mV to
+122.4 mV
440 mV
3.4 V 0 3.4 V 3.46 V +117.6 mV to
+122.4 mV
3.34 V
0 2.4 V 2.46 V +117.6 mV to
+122.4 mV
2.34 V
-3.4 V 0 -3.4 V -3.34 V +117.6 mV to
+122.4 mV
-3.46 V
0 -2.4 V -2.34 V +117.6 mV to
+122.4 mV
-2.46 V
-1.5 V 0 -2.5 V -2.44 V +117.6 mV to
+122.4 mV
-2.56 V
0 -1.5 V -1.44 V +117.6 mV to
+122.4 mV
-1.56 V
0 -0.5 V -440 mV +117.6 mV to
+122.4 mV
-560 mV
Ch1 50 mV 0 V 0 0 V 150 mV +294 mV to
+306 mV
-150 mV
0 +1 V 1.15 V +294 mV to
+306 mV
850 mV
0 -1 V -850 mV +294 mV to
+306 mV
-1.15 V
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 191
