Input frequency Recovered clock baud rate
488.28 kHz 1.95 Mbaud
381 kHz 1.52 Mbaud
Figure 45: Clock recovery
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
280 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
