Tektronix DSA70000D Series Technical Reference

MSO70000C/DX,
DPO70000C/DX, DPO7000C,
MSO5000/B, and DPO5000/B
Series Oscilloscopes
Specifications and Performance Verification
Technical Reference
www.tek.com
077-0063-14
Warning
The servicing instructions are for use by qualified personnel only. To avoid
personal injury, do not perform any servicing unless you are qualified to do
so. Refer to all safety summaries prior to performing service.
This document supports product firmware version 6.8.0 and above.
Revision B

Tektronix DSA70000D Series Specifications

General

Channels	up to 4
Memory Depth	up to 1 Gpts
Vertical Sensitivity	1 mV/div to 1 V/div
Input Coupling	AC, DC, GND
Sample Rate	up to 100 GS/s
Input Impedance	50 Ω
Trigger Types	Edge, Runt, Timeout, Setup/Hold
Display	12.1-inch LCD
Vertical Resolution	8 bits
Interface	GPIB, USB, Ethernet
