Tektronix DSA70000D Series Technical Reference

DPO7054C, Enhanced
bandwidth
10 GS/s Analog bandwidth setting
Input Frequency 0.5 GHz
10 MHz 6.8 bits
510 MHz 6.8 bits
5 GS/s Analog bandwidth setting
Input Frequency 0.5 GHz
10 MHz 6.7 bits
510 MHz 6.7 bits
2.5 GS/s Analog bandwidth setting
Input Frequency 0.5 GHz
10 MHz 6.5 bits
510 MHz 6.4 bits
DPO7054C, Without enhanced
bandwidth
10 GS/s Analog bandwidth setting
Input Frequency 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 6.5 bits 6.6 bits 6.7 bits
510 MHz 6.4 bits
5 GS/s Analog bandwidth setting
Input Frequency 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 6.5 bits 6.6 bits 6.7 bits
510 MHz 6.4 bits
2.5 GS/s Analog bandwidth setting
Input Frequency 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 6.5 bits 6.6 bits 6.7 bits
510 MHz 6.4 bits
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 27
