Tektronix DSA70000D Series Technical Reference

The MSO/DPO5204/B and MSO/DPO5104/B models have separate 50 Ω and 1 MΩ analog paths,
so they must be tested at both settings. All other models have one analog path, so the analog path
is fully tested with the 50 Ω termination.
Analog bandwidth with TPP0500
and TPP1000 probe, typical
Full bandwidth, with amplitude tolerance of -3 dB and operating temperatures of ≤30 °C (86 °F).
Reduce the bandwidth by 1% for each °C above 30 °C.
Instrument SCALE range Bandwidth
MSO5204/B,
DPO5204/B,
MSO5104/B,
DPO5104/B
50 mV/div — 100 V/div DC to 1 GHz (TPP1000 probe)
DC to 500 MHz (TPP0500
probe)
20 mV/div — 49.8 mV/div DC to 350 MHz
10 mV/div — 19.9 mV/div DC to 175 MHz
MSO5054/B,
DPO5054/B
50 mV/div — 100 V/div DC to 500 MHz
20 mV/div — 49.8 mV/div DC to 350 MHz
10 mV/div — 19.9 mV/div DC to 175 MHz
MSO5034/B,
DPO5034/B
50 mV/div — 100 V/div DC to 350 MHz
20 mV/div — 49.8 mV/div DC to 350 MHz
10 mV/div — 19.9 mV/div DC to 175 MHz
Lower frequency limit, AC coupled,
typical
< 10 Hz when AC, 1 MΩ coupled
The AC coupled lower frequency limits are reduced by a factor of 10 when 10X passive probes are
used.
Upper frequency limit, 250 MHz
bandwidth limited, typical
250 MHz, ±20%
Upper frequency limit, 20 MHz
bandwidth limited, typical
20 MHz, ±20%
Calculated rise time, typical Calculated Rise Time at 350/BW (MHz). The formula is calculated by measuring -3 dB bandwidth
of the oscilloscope. The formula accounts for the rise time contribution of the oscilloscope
independent of the rise time of the signal source.
Instrument 50 Ω
10 mV/div to 1 V/
div
50 Ω
5 mV/div to
9.98 mV/div
50 Ω
2 mV/div to
4.99 mV/div
50 Ω
1 mV/div to
1.99 mV/div
MSO5204/B,
DPO5204/B
175 ps 233 ps 1 ns 2 ns
Instrument 50 Ω
5 mV/div to 1 V/
div
50 Ω
2 mV/div to
4.99 mV/div
50 Ω
1 mV/div to
1.99 mV/div
MSO5104/B, DPO5104/B 350 ps 1 ns 2 ns
MSO5054/B, DPO5054/B 700 ps 1 ns 2 ns
MSO5034/B, DPO5034/B 1 ns 1 ns 2 ns
Analog channel input and vertical specification (cont.) Specifications (MSO/DPO5000/B Series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 81
