To reset the instrument RAM, do the following:
1. Power off the instrument for at least 20 seconds.
2. Power on the instrument.
Disable the LAN port and clear the LAN Ethernet settings
To disable the LAN port and clear LAN Ethernet settings, such as IP addresses,
complete the steps in this procedure.
CAUTION. This procedure clears network connectivity information. Record all of
the settings before clearing them.
1. Remove the network cable from the LAN port on the rear of the instrument.
2. Push the front-panel Default Setup button.
3. Push the front-panel Utility button.
4. Push the Utility Page lower-bezel button and use the Multipurpose a knob
to select I/O.
5. Push the Network Configuration lower-bezel button.
6. Push the Manual side-bezel button. Wait for this operation to complete.
7. Push the Set IP Address Manually side-bezel button.
8. Push the ↑ or ↓ arrow side-bezel button to position the cursor on the
Instrument IP Address field.
9. Push the Clear lower-bezel button.
10. Push the ↓ arrow side-bezel button to position the cursor on the Gateway IP
Address field.
11. Push the Clear lower-bezel button.
12. Push the ↓ arrow side-bezel button to position the cursor on the Subnet
Mask field.
13. Push the Clear lower-bezel button.
14. Push the ↓ arrow side-bezel button to position the cursor on the DNS IP
Address field.
15. Push the Clear lower-bezel button.
16. Push the OK Accept side-bezel button.
17. Push the Ethernet and LXI lower-bezel button.
18. Push the –more- 1 of 2 side bezel button to get to the second page of side
bezel menus.
19. Push the Change Names side-bezel button.
Clear and sanitize procedures
8 MDO3000 Series Declassification and Security Instructions
