Installing your instrument
Check shipped accessories
Make sure that you received everything you ordered. If anything is missing, contact Tektronix Customer Support. In North
America, call 1-800-833-9200. Worldwide, visit www.tek.com to find contacts in your area.
Check the packing list that came with your instrument to verify that you have received all standard accessories and ordered
items. If you purchased factory options, tap Help > About to confirm that the option(s) are listed in the Installed Options table.
Standard accessories
Item Quantity Tektronix part number
3 Series MDO (MDO34, MDO32) Installation and Safety Manual 1 071-3608-xx
Passive Voltage Probe, depends on instrument bandwidth
(350 MHz, 500 MHz, and 1 GHz bandwidth)
(100 MHz and 200 MHz bandwidth)
One per analog channel
TPP0500B
TPP0250B
Accessory bag 1 016-2144-xx
Power cord 1 Depends on region
Calibration certificate 1 N/A
OpenChoice
®
Desktop Software (available for download from www.tek.com/
software/downloads.)
Safely rotate the handle
Use the correct process to eliminate the chance of pinching your thumb or rear-panel-connected cables while rotating the handle.
CAUTION. Hold the top of the handle to rotate the handle on the instrument. Do not hold the handle from the sides and rotate, as
this can pinch the base of your thumb between the handle and the case.
If you have routed any cables between the handle and the case, be careful when rotating the handle so that you do not pinch the
cables.
MDO32, MDO34 Installation and Safety Manual 1
