Display Waveform Data
Setting the LCD Backlight
1. Push Utility.
2. Push Utility Page.
Utility Page
3. Turn multipurpose knob a and select Display.
Display
4. Push Backlight Inte nsity.
Utility Page
Display
Backlight
Intensity
High
Graticule
Full
Screen
Annotation
MSO4000 and DPO4000 Series Oscilloscopes User Manual 167
