Tektronix MSO2000 series User Manual

Application Examples
2. Push Add Measurement.
Add Mea-
surement
Remove
Measure-
ment
Indicators
More
Bring
Cursors On
Screen
Configure
Cursors
3. Turn multipurpose knob a to select the
Amplitude measurement from the side menu.
If needed, press Source and turn mu ltipurpose
knob b to select channel 1.PushOK Add
Measurement from the side menu. Rep eat
this process to select channel 2 and again
push OK Add Measuremen t from the s ide
menu.
MSO4000 and DPO4000 Series Oscilloscopes User Manual 275
