Application E xamp les
1. Push Acquire.
2. Push M ode.
Mode
Sample
Record
Length
10K
Delay
On |
Off
Set Horiz.
Position to
10%
Waveform
Display
XY Display
Off
3. Push Average on the side-bezel me nu.
Average
286 MSO4000 and DPO4000 Series Oscilloscopes User Manual
