Getting Started with the MSO/DPO2000 , M SO/DPO30 00, and MSO/DPO4000 Series Oscilloscopes
5. Push the front-panel Select button.
This lets you expand or contract your view into
the contents of the drive that you are using.
Expanded list Contracted list
6. Select the desired file format with the
side-bezel button.
File Format
.png
7. Push OK Save Screen Image.
OK
Save
Screen
Demo 2 Board Instruction Manua l 19
