Acquire the Signal
1. If you selected RS-232, push Configu re and
the desired side-bezel menu choices.
Bus
RS-232
Define
Inputs
Thresholds
Configure
9600-8-N
B1 Label
RS-232
Bus Display Event Table
Use the side-bezel me nu to configure the
bus. Use Normal polarity to trigger o n
RS-232 signals and Inverted polarity to trigger
on RS-422, RS-485, and UART signals.
