Tektronix MSO2012

Display Waveform Data
Setting the Display Style and Persistence
1. To set the display style, push Acquire.
2. Push Waveform Display .
Average
Off
Record
Length
100k
Delay
On|Off
Set Horiz.
Position to
0s
Waveform
Display
XY Display
Off
Acquisition
Details
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 147
