Analyze Waveform Data
Customizing an Automatic Measurement
You can customize automatic measurements by using gating, taking a snapshot, or setting the high and low levels.
Gating
Gating connes the measurement to a certain portion of a waveform. To use:
1. Push Measure.
2. Push Gating.
Add Mea-
surement
Remove
Measure-
ment
Indicators
Gating
Screen
High-Low
Method
Auto
Bring
Cursors On
Screen
Congure
Cursors
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 181
