Installation
Operating Considerations
DPO2000 and MSO2000 Series Oscilloscopes
Input Voltage: 100 V to 240 V ±10%
Input Power Frequency:
50/60 Hz at 100 V to 240 V
400 Hz at 115 V
Power Consumption: 80 W maximum
Weight: 3.6 kg (7 lbs 14 oz), stand-alone oscilloscope
Height, including th e feet but not the handle:
175 mm (6.885 inch)
Width: 377 m m (14.85 inch)
DPO2000 series
Depth: from the feet to the front o f the knobs: 134 mm (5.3 inch)
Depth: f rom the feet to the front of the front cover: 139 mm (5.47 inch)
Clearance: 50 mm (2 inch)
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 7
