Trigger Setup
Trigger type Trigger conditions
Video
Trigger on specified fields or lines of a c omp osite video
signal. Only com posite signal formats are supported.
Trigger on N TSC, PAL, or SECAM. Works with Macrovision
signals.
Bus Trigger on various bus conditions.
I
2
C requires a DPO2EMBD module.
SPI requires a DPO2EMBD module.
CAN requires a DPO2AUTO module.
LIN requires a DPO2AUTO module.
RS-232, RS-422, RS-485, and UART require a
DPO2COMP module.
Parallel requires an MSO2000 series oscilloscope.
(See page 23, Application Mo dule Free Trial.)
134 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
