Save and Recall Information
2. Push R1 or R2.
(R1) |
(On)
(R2) |
(Off)
Removing a Reference Waveform from the Display. To remove a reference waveform from the display:
1. Push Ref R.
2. Push the R1 or R2 lower-bezel button to
remove the reference w aveform from the
display.
(R1) |
(On)
(R2) |
(Off)
The reference waveform is still in nonvolatile
memory and can be displayed again.
220 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
