Tektronix MSO4054 Demo Instruction Manual

Giving Demos of Advanced Tektronix 4000 Features
Hex
12. Select Binary from the side-bezel menu to
show that you can decode into either Hex or
Binary. Switch back to Hex,asitiseasierto
view.
Binary
Hex Binary
13. Push the lower-bezel Event Table button.
Tektronix 4000 Oscilloscope Demo In struction Manual 45
