T
rigger
Setup
Starting
and
Stopping
an
Acquisition
After
yo
u
ha
ve
de
fi
ned
the
acquisition
and
trigger
parameters,
start
the
acquisition
with
Run/Stop
or
Single
.
Push
Run/Stop
to
start
acquisitions.
The
oscilloscope
acquires
repeatedly
until
you
push
the
button
again
to
stop
the
acquisiti
on.
Push
Single
to
take
a
single
acq
uisition.
Single
sets
the
trigger
m
ode
to
Normal
for
the
single
acq
uisition.
160
MSO4000
and
DPO4000
Series
Oscilloscopes
User
Manual
185
187
