Tektronix MSO4054 User Manual

Save and Recall Information
2. Push R1, R2, R3,orR4.
(R1) |
(On)
(R2) |
(Off)
(R3) |
(Off)
(R4) |
(Off)
Removing a reference waveform from the display. To remove a reference waveform from the display:
1. Push Ref R.
2. Push the R1, R2, R3,orR4 lower-bezel button
to remove the reference waveform from the
display.
(R1) |
(On)
(R2) |
(Off)
(R3) |
(Off)
(R4) |
(Off)
The reference waveform is still in nonvolatile
memory and can be displayed again.
246 MSO4000 and DPO4000 Series Oscilloscopes User Manual
