Acquisition

3. Push Autoset.

4. Adjust the ver

tical position, scale, and offset using the front-panel knobs.

MSO5000B

and DPO5000B Series

MSO/DPO7 0000DX, MSO/DPO70000C, and DPO7000C Se r ies

5. Adjust th

e horizontal position and scale using the front-panel knobs.

The horizontal position determines the number of pretrigger and posttrigger samples.

MSO5000B and D PO5000B Series

MSO/DPO7 0000DX, MSO/DPO70000C, and DPO7000C Se r ies

34 MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO 5000B Series U ser M anual
