Tektronix MSO54 Service Manual

Index
number
Tektronix part
number
Serial no. effective Qty Name & description
-3 407-5865-XX 1 BRKT, 120MM X 38MM FAN, SAFETY CONTROLLED
-4 348-2082-XX 4 GROMMET, FAN MOUNT, NOISE DAMPING
-5 441-2826-XX Below B020000
Below C040000
1 CHASSIS, REAR, SAFETY CONTROLLED
441-2945-XX B020000 and above
C040000 and above
1 CHASSIS, REAR
-6 878-1143-XX 1 CIRCUIT BOARD SUBASSY; AFG RISER BOARD UNTESTED;
389494600
Return the instrument to T
ektronix for service.
-7 348-2264-XX 2 GASKET, CONDUCTIVE, FOF, 1MM X 10MM X 100MM
-8 337-4731-XX 1 SHIELD, INSULATOR, POWER SUPPLY, SAFETY CONTROLLED
-9 214-3903-XX 4 SCREW, JACK; 4-40 X 0.312 LONG, 0.188 HEX HEAD STAND OFF W/
ASSEMBLED SPLIT LOCK WASHER, 4-40 INT THD, X 0.312 THD EXT
4-40, STEEL, ZINC PLATED
-10 119-8742-XX 1 FILTER, EMI; AC LINE FILTER; 10.0A,120-250VAC, DC-400 HZ,
IEC INPUT ,FAST-ON/SOLDER LUG OUTPUT, CHASSIS MOUNT;
FN9244R10-06; SAFETY CONTROLLED
-11 335-3420-XX 1 LABEL, REAR, IO, SAFETY CONTROLLED
-12 211-1571-XX 4 SCREW, MACHINE, M3 X 0.5 X 40MM PAN HEAD, TORX T8 WITH
NYLON PATCH
-13 119-8639-XX 1 FAN ASSEMBLY,119864000 W / TERMINATION, SAFETY
CONTROLLED
-14 361-1883-XX 4 SPACER, RND, 6MM OD X 3.2MM ID X 25MMLG
-15 065-1005-XX Below B020000
Below C040000
1 MODULE ASSY: SERVICE REPLACEMENT KIT; CARRIER
INTERFACE BOARD; WITH BIOS AND SSD; FULLY TESTED; MSO5
SERIES
Return the instrument to Tektronix for service.
065-1076-XX B020000 and above
C040000 and above
1 MODULE ASSY: SERVICE REPLACEMENT KIT;CARRIER INTERFACE
BOARD;WITH BIOS AND SSD; FULLY TESTED; MSO5 SERIES
Return the instrument to Tektronix for service.
Table continued…
Replaceable parts
5 Series MSO Service Manual MSO54, MSO56, MSO58 40
