The cursor configuration menu in an XY plot.
6.
T
o split the cursors between two waveforms, tap the
Source
field and select
Split
and select the source for each cursor
. The cursors
are moved to the specified waveforms.
7.
T
ap the Help icon on the menu title for more information on the menu settings.
8.
T
o stop showing cursors, open the Cursors configuration menu and set Display to
Off
.
Operating basics
