Install your ins

trument

MSO5000B and DPO5000 B models

1. Turn off power.

2. Connect second monitor.

3. Connect keyboard.

4. Connect mouse.

5. Turn on instrument power.

6. Turn on monitor power.

MSO5000B a nd DPO5000B models

14 MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO 5000B Series U ser M anual
