Specifications
4
P6137 10X Passive Probe Instructions
Figure 5: Typical voltage derating versus frequency
Table 2: Environmental Characteristics
Characteristics Description
Temperature Range
Operating –15_C to +65_C (+5_F to +149_F)
Non-Operating –62_C to +85_C (–80_F to +185_F)
Humidity Five cycles (120 hr) at 95% to 97% relative
humidity. Per Tek Standard 062–2847–00, Class 3.
Refer to MIL-E-16400F, paragraphs 4.5.9 through
4.5.9.5.1, Class 4.
Table 3: Physical Characteristics
Characteristics Description
Probe Cable Length 1.5 m ( 5 ft)
Net Weight 109 g (3.9 oz)
Safety
To avoid explosion, do not operate this product in an explosive atmosphere
unless it has been specifically certified for such operation.
This product meets the requirements of UL 1244.
