DCM910 Specifications
Handheld and Benchtop Instruments Basic Service
3
Table 1: Electrical Characteristics (Cont.)
Characteristic Description
Accuracy
0 A to 20 A ±(1.9% of reading + 10 counts)
20.1 A to 400 A ±(1.9% of reading + 40 counts)
401 A to 1000 A ±(2.9% of reading + 5 counts)
Frequency, Auto Ranging
Ranges 4 kHz and 10 kHz
Sensitivity 6 A
RMS
(10 A
RMS
, 1kHz to 10 kHz)
Resolution
4 kHz Range 1 Hz
10 kHz Range 10 Hz
Accuracy ±(0.5% of reading + 3 counts)
Peak Hold
Range Low, High
Resolution
Low 0.1 A
High 1.0 A
Accuracy ±(3% of reading + 10 counts)
Table 2: General Specifications
Characteristic Description
Auto Power Off Approximately 30 minutes
Battery 9 V, NEDA1604, IEC6F22, JIS 006P
Battery Life 40 hours (alkaline)
Maximum Conductor Size 51 mm (2 inch) diameter or 24 × 60 mm (.95 × 2.36 inch) bus bar
