Tektronix TBS2202B Service Manual

Fig. &
index
number
Tektronix part number Serial no.
effective
Serial no.
discont'd
Qty
1
Name & description
-5 146-0148-xx 1 BATTERY, DRY: 3 VOLT, 150MAH, LITHIUM, LEADED
BUTTON CELL, SAFETY
CONTROLLED
-6 174-6286-xx 1 CABLE ASSEMBLY (LINE INPUT), SAFETY CONTROLLED
-7 131-6643-xx 2 CONTACT, ELECTRICAL
-8 441-2847-xx 1 CHASSIS; REAR, SAFETY CONTROLLED
-9 119-7086-xx 1 FILTER, EMI; AC LINE CONNECTOR/INPUT FILTER; 6.0A,
120-250VAC, DC-400 HZ
-10 211-0718-xx 2 SCREW, MACHINE; 6-32 X 0.312, FLH100, STEEL, ZINC
FINISH, T-10 TORX DR
-11 850-0443-xx 1 CASE, REAR, SAFETY CONTROLLED
-12 367-0598-xx 1 HANDLE, CARRYING OVERMOLDED, SAFETY
CONTROLLED
-13 214-5148-xx 2 SPRING FRONT FOOT
-14 348-1909-xx 2 FOOT REAR
-15 348-2222-xx 2 FOOT, FRONT CABINET, HINGED
-16 335-3427-xx 1 LABEL, IO (REAR)
-17 348-2082-xx 4 GROMMET, FAN MOUNT, NOISE DAMPING
-18 119-8751-xx 1 FAN, TUBE AXIAL (92MM, DC, ASSEMBLY)
-19 878-1137-xx 1 CIRCUIT BOARD (IO BOARD)
-20 870-1169-xx 1 CIRCUIT BOARD MAIN BOARD
-21 129-1693-xx 1
3
SCREW, JACK, 433H, 6-32 INTERNAL, 8-32 EXTERNAL
-22 878-1139-xx 1 CIRCUIT BOARD ASSY, ANALOG FRONT END BOARD,
-23 210-1039-xx 4 WASHER, LOCK INTERNAL TOOTH
-24 220-0265-xx 4
4
NUT, PLAIN, HEX; 0.5-28 X 0.625 HEX, BRS, NKL PL
-N/A 119-8771-xx 1
5
WIFI USB DONGLE FOR TBS
3
Tightening torque for 129-1693-xx is 1.13 N*M.
4
Tightening torque for 220-0265-xx is 4.52N*M, ±0.23 N*M.
5
Tektronix option TEKUSBWIFI.
Replaceable parts
26 TBS2000B Series Service Manual
