TDS 340A, TDS 360 & TDS 380 Technical Reference
5–1
Adjustment Procedures
This chapter contains information you need to adjust the TDS 340A, TDS 360,
and TDS 380. There are only three types of adjustments you can perform on the
oscilloscope: the automated and semiautomated adjustments in the system
calibration menu, attenuator adjustments, and monitor adjustments.
You should do the signal path compensation adjustment after servicing your
instrument or moving your instrument to a new operating environment (±5_ C
temperature change). The other adjustment procedures may be necessary if the
instrument fails one of the Performance Tests in the previous section.
Let the instrument warm up for 20 minutes before performing any adjustments.
Adjustment Interval. These adjustments should be done once a year.
Equipment Required
Table 5–1 lists the equipment you will need to do the adjustment procedures.
Table 5–1: Adjustment equipment
Item number
and description
Minimum requirements Example Purpose
1. Adjustment Tool 0.075 inch slot screwdriver Tektronix part number
003-1433-01 (standard probe
adjustment tool)
Monitor and attenuator adjust-
ments
2. Termination, 50 W Impedance 50 W; connectors:
female BNC input, male BNC
output
Tektronix part number
011-0049-01
Timing calibration and attenua-
tor adjustment
3. Cable, Precision Coaxial 50 W , 36 in, male to male BNC
connectors
Tektronix part number
012-0482-00
Attenuator adjustments and
system calibration
4. Generator,
DC Calibration
Variable amplitude to ±10 V;
accuracy to 0.05%
Wavetek 9100 Calibration
System with Option 250
Voltage and external trigger
calibrations
5. Generator,
Fast-rise Step
t
r
10 ns;
amplitude 1 V
p-p
Wavetek 9100 Calibration
System with Option 250
Timing calibration and attenua-
tor adjustment
