Page #144 background imageLoading...
Page #144 background image
TDS 340A, TDS 360 & TDS 380 Technical Reference
7–1
Options
This chapter describes the various options, as well as the standard and optional
accessories, that are available for the TDS 340A, TDS 360, and TDS 380.
Options
The available options are the Option 14 I/O Interfaces, Options A1-A5 (interna-
tional power cords), manual language options, and warranty service options. The
following sections describe each of these options.
This option includes GPIB, RS-232, and Centronics interfaces, VGA video
output, and power for the DPU 411 printer. It also includes the TDS 340A,
TDS 360 & TDS 380 Programmer Manual.
You can connect a remote display to the VGA 9-pin D connector on the rear
panel. Table 7–6 on page 7–4 gives the part number of a properly shielded cable
that is commercially available.
Because display manufacturers use different pin combinations and connectors,
you may find the information in Table 7–1 helpful.
Table 7–1: VGA output connector pins
Pin Signal
2 Video (monochrome analog)
4 Horizontal sync @ 31.5 kHz (VGA rate)
5 Vertical sync
6, 7, 8 Ground
Option 14: I/O Interfaces
