Options
7–4
TDS 340A, TDS 360 & TDS 380 Technical Reference
Accessory Probes
These are other types of probes you can use with the TDS 340A, TDS 360, and
TDS 380. You can order the following probes separately:
H P6101B 1X Passive Probe
H P6129B Switchable 1X-10X Passive Probe (not recommended for the
TDS 360 or TDS 380)
H P6408 TTL Logic Probe
H P5100 High Voltage Probe
H P5200 High-Voltage Differential Probe
H AM503S DC/AC Current Probe System
H P6561AS SMD Small-Geometry Probe
Accessory Cables
Table 7–6 lists cables you can use with the TDS 340A, TDS 360, and TDS 380.
You can order them separately.
Table 7–6: Accessory cables
Cable type Part number
GPIB,1 meter (3.3 feet) 012-0991-01
GPIB, 2 meter (6.6 feet) 012-0991-00
RS-232, 9-pin female to 9-pin female connectors, null
modem, 76 inch (for AT style computers)
012-1379-00
RS-232, 9-pin female to 25-pin female connectors, null
modem, 76 inch (for PC style computers)
012-1380-00
RS-232, 9-pin female to 25-pin male connectors, null
modem, 9 feet (for serial interface printers)
012-1298-00
RS-232, 9-pin female to 25-pin male connectors, 15 feet
(for modems)
012-1241-00
Centronics, 25-pin male to 36-pin Centronics,
2.4 meter (8 feet) (for parallel printer interfaces)
012-1214-00
NECR VGA video cable. (Use an appropriate adapter
when other than a 9-pin monitor connection is needed.)
73893029
