Preface
xiv
TDS 340A, TDS 360 & TDS 380 Technical Reference
Diagrams contains component location and schematic diagrams.
Mechanical Parts List includes a table of all replaceable modules, their
descriptions, and their Tektronix part numbers.
Manual Conventions
This manual uses certain conventions which you should become familiar with
before doing service.
Throughout this manual, any replaceable component, assembly, or part of this
digitizing oscilloscope is referred to generically as a module. In general, a
module is an assembly, like a circuit board, rather than a component, like a
resistor or an integrated circuit. Sometimes a single component is a module; for
example, the chassis of the oscilloscope is a module.
Symbols and terms related to safety appear in the General Safety Summary and
Service Safety Summary found at the beginning of this manual.
Besides the symbols related to safety, this manual uses the following symbols:
STOP. This “stop sign” labels information which you must read in order to
correctly do service and to avoid incorrectly using or applying
service procedures.
Related Manuals
These other manuals are available for the TDS 340A, TDS 360, and TDS 380
Digitizing Oscilloscopes.
The Reference Manual gives you a quick overview of how to operate your
oscilloscope.
The User Manual provides instructions on how to operate your oscilloscope.
The Programmer Manual provides complete information on programming
and remote control of the oscilloscope through the GPIB or RS-232 interface
(optional accessory).
