TDS 340A, TDS 360 & TDS 380 Technical Reference
6–5
Removal and Replacement
This section contains procedures for removal and installation of all mechanical
and electrical modules.
Preparation — Please Read
WARNING. To avoid injury or death, disconnect the power cord from the line
voltage source before performing any procedure in this section.
STOP. READ THESE GENERAL INSTRUCTIONS BEFORE REMOVING A
MODULE.
First locate the module you want to remove in the exploded views (Figures 10–1
and 10–2 on pages 10–6 and 10–8). Then read Equipment Required for a list of
the tools needed to remove and install modules in this oscilloscope.
To remove an internal module, you need only remove the oscilloscope cabinet
(page 6–11) and then perform the removal procedure for that module. The
internal modules are independently removable.
Procedures will refer to “front,” “rear,” “top,” etc. of the oscilloscope; note
from Figure 6–1 which sides are referenced.
