Frcss tie front-panel button SAVEmCALL, the main-menu bul:ton Recall
Factory Setup, and then the side-menu button OK Confirm Factory Init.
Press AUTOSET.
Set the VOLTS/DIV to 1 V. USC lhc vertical
POSITION
knob to ccntcr the
waveform vertically on screen.
Set the SEC/DIV to 250 ps.
Check that a square wave probe-com,pen,sation signal of about five divisions
in amplitude is on screen.
Cheek that one period of the square wave probe-compensation signal is
about four horizontal divisions on screen.
Check that the horizontal POSInON knob positions the signal Icft and right
on screen when rotated.
Press the front-panel button TRIGGER MENU, the main-menu button
Mode, and then the side-menu button Normal.
10. Check that the trigger-level. readout for the main trigger system changes with
the trigger LEVEL knob.
‘Il.
Cheek that the trigger-level knob can trig&r and untrigger the square-wave
signal as you rotate it. (Leave the signal untriggcred.)
12. Check that pressing SET LEVEL TO 50% triggers the signal that you just
left untriggcred.
13. Press the front-panel button ACQUIRE, the main-menu button Mode, and
rhcn the side-menu button Sample.
14. Check that UK oscilloscope displays an actively acquiring waveform
on-screen. (Note tbdt there is noise present on the peaks of the square wave.)
15. Press the side-menu button Peak Detect. Cheek that the oscilloscope displays
an actively acquiring waveform on screen with the. noise “peak detcctcd.”
16. ‘Press the side-menu button Envelope. Check that the oscilloscope displays
an actively acquiring waveform on screen with the noise displayed.
17. Press the side-menu button Average. Check that the osciIloscope displays an
actively acquiring waveform on screen with the noise reduced.
18. Press WAVEFORM OFF to remove Channel 1 from the display.
19. Press CB 2 and move the probe to the CH 2 input.
20. Repeat steps 3 through 17 for Charm&l 2.
TDS 340, T!X 360 & TDS 380 User Manual
