Tektronix TDS 500C Programmer's Manual

Command Groups
TDS Family Oscilloscope Programmer Manual
2–33
Table 2–21: Trigger Commands (Cont.)
Header Description
TRIGger:MAIn:PULse:RUNT:POLarity
(TDS 510A, 500C, 600B, & 700C)
Runt trigger positive, negative, or both
TRIGger:MAIn:PULse:RUNT:THReshold?
(TDS 510A, 500C, 600B, & 700C)
Return runt trigger thresholds
TRIGger:MAIn:PULse:RUNT:
THReshold:BOTh
(TDS 500C, 600B & 700C)
Trigger level switching thresholds
TRIGger:MAIn:PULse:RUNT:
THReshold:HIGH
(TDS 510A, 500C, 600B, & 700C)
Upper limit for runt pulse
TRIGger:MAIn:PULse:RUNT:
THReshold:LOW
(TDS 510A, 500C, 600B, & 700C)
Lower limit for runt pulse
TRIGger:MAIn:PULse:RUNT:WHEn
(TDS 500C, 600B & 700C)
Runt pulse width type to check for
TRIGger:MAIn:PULse:RUNT:WIDth
(TDS 500C, 600B & 700C)
Minimum width for valid main pulse runt trigger
TRIGger:MAIn:PULse:SLEWRate:
DELTATime
(TDS 500C, 600B & 700C)
Slew rate trigger delta time
TRIGger:MAIn:PULse:SLEWRate:
POLarity
(TDS 500C, 600B & 700C)
Slew rate trigger polarity
TRIGger:MAIn:PULse:SLEWRate:
SLEWRate?
(TDS 500C, 600B & 700C)
Return slew rate value
TRIGger:MAIn:PULse:SLEWRate:
THReshold:BOTh
(TDS 500C, 600B & 700C)
Upper and lower slew rate trigger thresholds
TRIGger:MAIn:PULse:SLEWRate:
THReshold:HIGH
(TDS 500C, 600B & 700C)
Upper limit for slew rate pulse
TRIGger:MAIn:PULse:SLEWRate:
THReshold:LOW
(TDS 500C, 600B & 700C)
Lower limit for slew rate pulse
TRIGger:MAIn:PULse:SLEWRate:WHEn
(TDS 500C, 600B & 700C)
Slewing signal type to check for
TRIGger:MAIn:PULse:SOUrce
(TDS 510A, 500C, 600B, & 700C)
Pulse trigger channel
TRIGger:MAIn:PULse:TIMEOut:POLarĆ
ity
(TDS 500C, 600B, & 700C)
Pulse timeout trigger polarity
