Command Groups
2–34
TDS Family Oscilloscope Programmer Manual
Table 2–21: Trigger Commands (Cont.)
Header Description
TRIGger:MAIn:PULse:TIMEOut:TIMe
(TDS 500C, 600B, & 700C)
Pulse timeout trigger time
TRIGger:MAIn:PULse:WIDth?
(TDS 510A, 500C, 600B, & 700C)
Return trigger pulse width parameters
TRIGger:MAIn:PULse:WIDth:HIGHLimit
(TDS 510A, 500C, 600B, & 700C)
Pulse trigger maximum pulse width
TRIGger:MAIn:PULse:WIDth:LOWLimit
(TDS 510A, 500C, 600B, & 700C)
Pulse trigger minimum pulse width
TRIGger:MAIn:PULse:WIDth:POLarity
(TDS 510A, 500C, 600B, & 700C)
Pulse trigger positive, negative, or both
TRIGger:MAIn:PULse:WIDth:WHEn
(TDS 510A, 500C, 600B, & 700C)
Pulse trigger when pulse detected or when not
detected
TRIGger:MAIn:TYPe Set main trigger to edge, logic, pulse, or, with
option 05, video type
TRIGger:MAIn:VIDeo?
(Option 05)
Return video trigger parameters
TRIGger:MAIn:VIDeo:BY
(TDS 400A Option 05)
Set video trigger delay mode
TRIGger:MAIn:VIDeo:FIELD
(Option 05)
Set video trigger field
TRIGger:MAIn:VIDeo:FIELDType
(TDS 510A, 500C, 600B, & 700C Option 05)
Set video trigger field type
TRIGger:MAIn:VIDeo:FLEXformat?
(TDS 510A, 500C. 600B, & 700C Option 05)
Return FlexFormat parameters
TRIGger:MAIn:VIDeo:FLEXformat:
FIELDRATE
(TDS 510A, 500C, 600B, & 700C Option 05)
Set FlexFormat frames per second
TRIGger:MAIn:VIDeo:FLEXformat:
FIELDS
(TDS 510A, 500C, 600B, & 700C Option 05)
Set FlexFormat video fields
TRIGger:MAIn:VIDeo:FLEXformat:
LINES
(TDS 510A, 500C, 600B, & 700C Option 05)
Set FlexFormat lines in a frame
TRIGger:MAIn:VIDeo:FLEXformat:
NEGSynchwidth
(TDS 510A, 500C, 600B, & 700C Option 05)
Set FlexFormat negative sync width
TRIGger:MAIn:VIDeo:FLEXformat:
V1STArttime
(TDS 510A, 500C, 600B, & 700C Option 05)
Set time from positive (+) edge of tri-sync
pulse for the last line in the selected field to
the leading edge (–) of the first negative
vertical sync pulse
