Tektronix TDS 500C Programmer's Manual

Command Groups
TDS Family Oscilloscope Programmer Manual
2–35
Table 2–21: Trigger Commands (Cont.)
Header Description
TRIGger:MAIn:VIDeo:FLEXformat:
V1STOptime
(TDS 510A, 500C, 600B, & 700C Option 05)
Set time from positive edge of tri-sync pulse
for the last line in the selected field (t
0)
to
trailing edge (positive) of the first negative
vertical sync pulse
TRIGger:MAIn:VIDeo:
FLEXformat:V2STArttime
(TDS 510A, 500C, 600B, & 700C Option 05)
Set time from t
0
to the leading edge (positive)
of the second vertical sync pulse
TRIGger:MAIn:VIDeo:
FLEXformat:V2STOptime
(TDS 510A, 500C, 600B, & 700C Option 05)
Set time from t
0
to trailing edge (positive) of
the second negative vertical sync pulse
TRIGger:MAIn:VIDeo:HDTv
(TDS 510A, 500C, 600B, & 700C Option 05)
Select high definition TV format
TRIGger:MAIn:VIDeo:HOLdoff?
(TDS 400A Option 05)
Return video trigger holdoff
TRIGger:MAIn:VIDeo:HOLdoff:VALue
(TDS 400A Option 05)
Set video trigger holdoff value
TRIGger:MAIn:VIDeo:INTERLAce
(TDS 400A Option 05)
Select video trigger interlace format
TRIGger:MAIn:VIDeo:LINE
(Option 05)
Set video trigger delay in terms of a number of
lines
TRIGger:MAIn:VIDeo:LINES
(TDS 400A Option 05)
Set video trigger delay in terms of a number of
lines
TRIGger:MAIn:VIDeo:NTSc
(TDS 510A, 500C, 600B, & 700C Option 05)
Select color or mono NTSC
TRIGger:MAIn:VIDeo:PAL
(TDS 510A, 500C, 600B, & 700C Option 05)
Select color or mono PAL
TRIGger:MAIn:VIDeo:SCAN
(TDS 400A Option 05)
Set video trigger scan rate
TRIGger:MAIn:VIDeo:SCANPeriod
(TDS 400A Option 05)
Set video trigger scan period
TRIGger:MAIn:VIDeo:SOUrce
Option 05
Select video trigger source
TRIGger:MAIn:VIDeo:STANdard
(TDS 510A, 500C, 600B, & 700C Option 05)
Select video trigger standard
TRIGger:MAIn:VIDeo:SYNc
(Option 05)
Select video trigger sync polarity
TRIGger:MAIn:VIDeo:SYStem
(TDS 400A Option 05)
Select video trigger class
